REPLACES ORIGINAL NUMBERS 6/1-130, 6-130, 6A-130 AND 6D-130 ON SOME REELS
Dura-Drag™ contains a special Phenolic bonding agent that prevents premature breakdown of the material while also providing a water-barrier. Dura-Drag™ is then pre-treated with a special formula developed by Penn Engineers through extensive testing and research. This special formula improves the drag performance, provides a barrier to prevent water damage, and gives the drag a silky, smooth feel from initial start-up through the entire drag run. The combination of new drag material and special formula gives anglers the toughest, smoothest, longest-lasting drag ever developed – a drag so revolutionary Penn trademarked it Dura-Drag™.
DESIGN CHANGE NOTES FOR UPGRADING TO NEWER DRAGS for 130 and 130H original internationals
This applies to these two older 130 and 130H models only, other newer models use the 6DN-130 as a stock part.
If your reel has the older separate asbestos/fiberglass drag washer system.
You cannot use 6DN-130 with the older outer and inner plates. They would also have to be changed, so you would need:
NOTES:
7A-130 floating washer was not changed and 118-80S DRIVE PLATE SCREWS (8 REQ.) remain the same.
