Model Specs:

More Info
  • Reinforced side plates.
  • Counterbalanced soft grip handle.
  • Chrome plated brass exposed metal componants.
  • Stainless steel ball bearings and pinion gear and a high strenth bronze alloy main gear.
  • Easy to operate star drag.
  • HT-100 multi-disc star drag.
  • Counterbalanced soft grip handle.
  • Dual Eccentric System.
Mono Cap
(yds/lb)
Braid Cap
(yds/lb)
Bearings Max Drag Gear Ratio Line Retrieve
220/20 -- 2 + 1 BB -- 3:1 --

Take Apart Construction

The term "Take-Apart" refers to the feature of quick and easy take-down of the reel for cleaning or spool change. To effect this, unscrew the knurled take-apart screw ( part TA 200 ) three turns to the left and then pull it outward ( away from plate ), at the same time rotate the right side plate about 1/4 inch to the left ( counter-clockwise ) and pull it away from the reel frame, taking care not to drop the freed spool. To re-assemble, reverse the entire operation, making sure to screw the take-apart screw into the reel frame, as otherwise the right side plate might be lost.
TA-200 became 129-200

REEL DISCONTINUED BY PENN

Many of these parts will become unavailable in the future.
Click above for more info

1N-100
001N-1180578
1N-100 Plate, Handle Side Plate

REPLACES ORIGINAL NUMBER 1-100

$41.90
2-155
002-1180628▲
2-155 Ring, Side Ring


MULTI USE See Description

$11.25
3-200
003-1180719▲
$13.90
5-60
005-1180826▲
$21.40
6-60
006-1180906◉
6-60 Washer, Drag Washer HT-100™

Used on multiple models in different quantities.

$1.30
UU-PENN100
CUU-PENN100▲
UU-PENN100 5+1 Drag Washer System (Custom)

Fits: 60, 60-LH, 65, 85, 99, 100M, 110, 140L, 140L-LH, 145, 146L, 149L, 150, 200M, 250, 259, 285M

$35.00
8-60CH
008-1181056☀
8-60CH Washer, Original Chrome Tension Spring Washer (Belleville)

Used on multiple models in different quantities.

$1.50
9-60
9-60
9-60 Sleeve, Spacing Sleeve - (optional variations)

Variations allow for more/less play in handle - see description.

$0.00
10-60
010-1181176▲
10-60 Star Drag Wheel (COARSE Thread - Two Types)

REPLACES ORIGINAL NUMBER 10-140 ON SOME REELS

$5.40
13-200
013-1181338
$18.35
14-155
014-1181399☀
$2.10
15-200
015-1181450☀
$5.90
16-60CH
016-1181565☀
16-60CH Screw

REPLACES ORIGINAL PART NUMBER 16-60 ON SOME REELS

Used on multiple models in different quantities.

$1.30
17-60CH
017-1181594☀
17-60CH Screw, Bridge, Upper Bridge Screw

REPLACES ORIGINAL PART NUMBER 17-60

Used on multiple models in different quantities.

$1.30
18-60
018-1181615☀
18-60 Spring, Clutch Spring

Used on multiple models in different quantities.

$1.30
19-200
019-1181671☀
$6.45
20-113H2
020-1288917♦
20-113H2 Spring, Eccentric Spring

REPLACES ORIGINAL NUMBER 20-155 and 20-220 ON SOME REELS

$1.30
20-155
020-1181769
20-155 Spring, Eccentric Spring

Used on multiple models in different quantities.
113H Fits All Versions.
Direct product replacement: 20-113H2 Spring, Eccentric Spring $1.30

$0.00
22-99
022-1181909☀
22-99 Screw, Eccentric Screw

113H Fits All Versions.

$2.30
23-60
023-1181935☀
23-60 Screw, Large

MULTI USE See Description

$4.55
24N-160
024N-160
24N-160 Handle, Flat Rubberized Knob

FITS: Type [A] Bridge/Sleeve

REPLACED BY PART NUMBER 24S-310

Direct product replacement: 24S-310 Handle, Brushed Stainless, Flat Rubberized Ergo Knob $0.00

$0.00
29L-100
029L-1191536
29L-100 Spool, Aluminum (Black)

REPLACES ORIGINAL NUMBER 29M-100 ON SOME REELS

$0.00
29M-100
029M-29M-100
$0.00
31-19
031-1182654☀
31-19 Screw

REPLACES OLD PART NUMBER 31-200

Used on multiple models in different quantities.

$1.30
32-16CH
032-1182709☀
32-16CH Screw

MULTI USE See Description

REPLACES ORIGINAL PART NUMBER 32-16 and 31-285 ON SOME REELS

$1.30
34-200
034-1182810▲
34-200 Screw, Clamp Screw (Longer for Thin Clamp) ONLY (uses 2)

This can be used as a sub for the 34-49 or 34-45 if wanting a LONGER stud screw

$2.55
35-155
035-1182919☀
$4.60
36-60CH
036-1182980☀
$1.80
37-180
037-1183074☀
37-180 Post, Frame Post


Optional on the 501 and 506HS reels.

$10.45
38-7
038-1183134☀
38-7 Screw

MULTI USE See Description

REPLACES ORIGINAL PART NUMBER 38-200 ON SOME REELS

$1.30
39-5
039-1183180☀
39-5 Screw


MULTI USE See Description

REPLACES ORIGINAL NUMBER 38-60 ON SOME REELS

$1.30
40-60
040-1183267☀
40-60 Bearing, Non-Handle Side

REPLACES ORIGINAL NUMBER 40-85 ON SOME REELS

$5.50
41-60
041-1183327☀
41-60 Spring

MULTI USE See Description

$1.35
110-60
110-1184437♦
110-60 Screw, Handle Lock Screw

REPLACES ORIGINAL PART NUMBER 23A-60 ON SOME REELS

$1.30
132-200
132-1184580
$1.30
168-60
168-1184802☘
168-60 Wrench

Fits 23-60, 23-16S knurled nuts (See details for list of reels)

$1.30
168-9
168-1184800
168-9 Wrench

Fits 23-60 knurled nut (see details for list of reels)
partimage

REPLACED BY PART NUMBER 168-60 or 168-TANI

Direct product replacement: 168-60 Wrench $1.30

$0.00
