Model Specs:

More Info
  • Precision, stainless-steel pinion gear.
  • Alloy main gear.
  • Sealed oil ports for quick, easy lubrication.
  • Side plates reinforced with metal rings.
  • Chrome plated brass exposed metal components for corrosion resistance.
  • HT-100 multi-disc star drag system.
  • Loud, durable, easy-to-service clicker.
  • Light weight with black anodized spool.
  • Soft grip counterbalanced handle. (Early models had torpedo knobs). 109 has a dual knob handle.
Mono Cap
(yds/lb)
Braid Cap
(yds/lb)
Bearings Gear Ratio
275/15 2 3.75:1
REEL DISCONTINUED BY PENN

Many of these parts will become unavailable in the future.
Click above for more info

1-109
001-1180445
$21.20
1-109-BURG
001-109BURG
$16.50
1N-109
001N-1180445
1N-109 Plate, Handle Side Plate, Black (NO oiler, newer design)

REPLACES ORIGINAL NUMBER 1-109

LIMITED QUANTITIES AVAILABLE

$21.25
2-109
002-109
2-109 Side Ring (Chrome)

MULTI USE See Description

Direct product replacement: 2N-109 Ring, Handle Side Ring (Stainless Steel) $7.30

$0.00
5-109
005-1180841▲
5-109 Gear, Main Gear

LIMITED QUANTITIES AVAILABLE

$9.85
5-109NC
005-1180841NC
5-109NC CLASSIC Main Gear

LIMITED QUANTITIES AVAILABLE - CLASSIC

$9.85
6-155
006-1180915◉
6-155 Washer, Drag Washer HT-100

MULTI USE See Description

Used on multiple models in different quantities.

$1.30
8-60CH
008-1181056☀
8-60CH Washer, Original Chrome Tension Spring Washer (Belleville)

Used on multiple models in different quantities.

$1.50
9-60
9-60
9-60 Sleeve, Spacing Sleeve - (optional variations)

Variations allow for more/less play in handle - see description.

$0.00
13-109
013-1181314
$15.80
15-109
015-1181434☀
$1.90
16-60CH
016-1181565☀
16-60CH Screw

REPLACES ORIGINAL PART NUMBER 16-60 ON SOME REELS

Used on multiple models in different quantities.

$1.30
17-60CH
017-1181594☀
17-60CH Screw, Bridge, Upper Bridge Screw

REPLACES ORIGINAL PART NUMBER 17-60

Used on multiple models in different quantities.

$1.30
19-109
019-1181659
19-109 Eccentric

LIMITED QUANTITIES AVAILABLE

$4.95
22-109
022-1181912☀
22-109 Screw (SEMS 540 x 156)

MULTI USE See Description

$1.90
23-180
023-1181948★
$8.20
24-85
024-1181985
24-85 Handle, Narrow Plastic Knob

FITS: Type [A] Bridge/Sleeve

REPLACES ORIGINAL PART NUMBER 24-109 ON SOME REELS

$0.00
24-109
024-1181996
24-109 Handle, Dual Narrow Plastic Knobs

FITS: Type [A] Bridge/Sleeve

REPLACED BY PART NUMBER 24-85

Direct product replacement: 24-85 Handle, Narrow Plastic Knob $0.00

$15.00
30N-9
030N-1182647
30N-9 Stand

REPLACES ORIGINAL NUMBER 30-109, 30-109S, 30-109F, 30-9 ON SOME OLDER REELS

$0.00
32-2
032-1182706☀
32-2 Screw

Used on multiple models in different quantities.

$1.30
35-155
035-1182919☀
$4.60
37-109
037-1183064☀
37-109 Post, Frame Post

REPLACES ORIGINAL PART NUMBER 37-77 ON SOME REELS

Used on multiple models in different quantities.

$3.85
39-1
039-1183177☀
39-1 Screw, Slotted


MULTI USE See Description
Used with orignal 24-30S handle

Used on multiple models in different quantities.

$1.30
42-109
042-1183345☀
42-109 Worm

REPLACES ORIGINAL NUMBER 42-9 ON SOME REELS

$4.25
43-109
043-1183375☀
43-109 Bearing, Worm Bearing

MULTI USE See Description

$2.55
45-109
045-1183482★
$6.60
46-109-COB
046-1183549▲
$5.50
046-109C
046-109C▲
46-109C Line Guide Assembly

REPLACES ORIGINAL PART NUMBER 46C-109

$13.35
47-109
047-1183614♦
$1.85
50-109
050-1183752☀
$4.60
57-109
057-1183927☀
57-109 Spring

MULTI USE See Description

Used on multiple models in different quantities.

$1.30
58-109
058-1183948☀
$5.50
Custom Sleeves Replacing: 98-155

Stainless Steel Gear Sleeves by other manufacturers. Click link to view options.

168-9
168-1184800
168-9 Wrench

Fits 23-60 knurled nut (see details for list of reels)
partimage

REPLACED BY PART NUMBER 168-60 or 168-TANI

Direct product replacement: 168-60 Wrench $1.30

$0.00
168-TANI
CUU-168-TANi▭
168-TANI Heavy Duty Penn Handle Nut Wrench by Alan Tani

Aftermarket Part - Not Manf. by Penn (see details for list of reels)
Fits 23-50S, 23-60, 23-114, 23-116, 23-220, 23-FTH20LW, 23-16S knurled nuts

$20.00
