>NOTE: Best viewed on PC or Tablet as this is a table
Differences between 112H and 112H2 reels |
||
|---|---|---|
| ** = not on this version | ||
| 112H | 112H2 | Part description |
| 1-112H | 1N-112H | handle side plate |
| 2-112H-O | 2-112H2-O | handle side ring outer |
| 2-112H-i | 2-112H2-i | inner side ring (uses 2) |
| 3-112H | 3N-112H | bridge (changed for handle) |
| 5-500 | 5-112H | main gear |
| 10-60 | 10-112H | star drag |
| 12-500 | 12-112H | pinion yoke |
| 13-500 | 13-112H | pinion |
| 22-99 | 22-112H2 | eccentric screw |
| 24-112H | 24N-112H or 24-113L2 | handle (NEEDS TO MATCH THE 98 STUD DUE TO DESIGN CHANGE) |
| 26-155 | ** | no handle side bearing or it's part of the new plate? |
| 27-112H | 27N-112H | non-handle side plate |
| 28-112H-O | 28-112H2 | non-handle side ring, outer |
| 29L-112H | 29N-112H | spool |
| 30-66 | ** | stand (replaced by frame on 112H2) |
| ** | 32-15 | handle nut cap screw |
| 32-17 | ** | non-handle side stand screw (used 2) |
|
33C-112H2 (backordered) Kit Contains: (1) 33N-113 Clamp (2) 34-16VS Stud Screw (2) 149-45 Long Nut (2) 149-200 Hex Nut (1) 168-112H Wrench |
rod clamp kit (changed studs due to frame) | |
| 34-45 | 34-16VS | clamp stud |
| 37-65 | 37-65 | 112H2 only uses 2 |
| 39-9 | ** | screw, post, handle side (used 5) |
| 39-3 | ** | screw, post, non-handle side (used 5), handle side stand screw (used 2) |
| ** | 39-112H | screw, plate (uses 10) |
| 40N-113HL | non-handle side bearing | |
| ** | non-handle side bearing spring | |
| ** | 55-113H | non-handle side bearing |
| 98-60 | 98-112H | gear sleeve (longer/diff threading f/handle) |
| ** | 120-113H | o'ring for non-handle side bearing |
| ** | 110A-555 | handle lock cap |
| ** | frame with decal | |
How to order these items, if interested in converting 112H to 112H2
- FIRST choose either ordering the complete bridge or just replacing the gear sleeve.
- SECOND Handle type MUST match the gear sleeve, Original 112H handle cannot fit on the 112H2 stud due to differences in design.
- THIRD select either just changing the clamp studs if you already have a clamp kit, or order the kit if you don't.
- NOTE: You also have the option of order a pair of new, clean 37-65 posts if you want the conversion to look complete, based on the condition of your current posts.
I put together these conversion notes because a couple of people asked about it, but it is far more practical just to order a new 112H2 reel complete.
Gear speed on both reels is 4:1, so at this time I haven't done a part to part
comparison of doing a gear to yoke change.
If you like the newer style handle, you could put one on the 112H without changing completely.
You'd need the 112H2 handle, handle lock cap, cap screw, handle nut screw and the
bridge or gear sleeve (depending on availability) from the list above.
~MizMo, Parts Dept.
