Model Specs:

More Info
  • Stainless steel pinion gear.
  • Manganese-bronze main gear.
  • Chrome-plated metal.
  • Anodized aluminum spool.
  • Multi-disc drag system.
  • Heavy-duty clicker.
  • One-piece rod clamp.
Mono Cap
(yds/lb)
Braid Cap
(yds/lb)
Bearings Gear Ratio
1150/30
700/50
625/60
1700/80
1450/100
1200/130
2 2.5:1
REEL DISCONTINUED BY PENN

Many of these parts will become unavailable in the future.
Click above for more info

115L-LH
115L Converting To Left Hand Parts

MUST READ!
Conversion NO longer possible, repair parts only.

$0.00
4-115
004-1180766☀
4-115 Washer, Hard Fiber Spacer Washer (Under Main Gear)

Used on multiple models in different quantities.
114H Fits All Versions.

$2.35
5-115LH
005-1180849
5-115LH Gear, Main Gear (Left Hand)


114H Fits All Versions.

$31.85
UU-PENN114H
UU-PENN114H▲
UU-PENN114H 7+1 Drag Washer System (Custom)

Fits: 114H, 114H-LH, 114HL, 114HLW, 115L, 115L-LH

Direct product replacement: UU-7C-115 Drag Stack 7+1 (CUSTOM) (METAL SET ONLY - See details) $37.00

$0.00
UU-7C-115
CUU-007C-115▲
$37.00
6-115
006-1180911◉
6-115 Washer, Drag Washer HT-100™

REPLACES ORIGINAL NUMBER 6-990 ON THE 990 REEL

$3.80
7C-115
007C-1181044▲
$12.35
10-114
010-1181185▲
10-114 Star Drag Wheel

114 Fits All Versions.

$8.25
12-114
012-1181262☀
12-114 Yoke, Pinion Yoke (Brass)

114 Fits All Versions.
114H Fits All Versions.

$2.80
12-114SS
CSD-012-114SS▲
12-114SS Yoke, Pinion Yoke (Stainless Steel, CUSTOM)

**For use with stainless gear set.

114 Fits All Versions.
114H Fits All Versions.

$4.50
13-114LH
013-1181324
$33.45
13-115LH
013-1191107
$23.20
14-116
014-1181397☀
$1.30
15-115
015-1181439☀
$2.30
17-114
017-1181596☀
$1.30
18-114
018-1181618☀
18-114 Spring, Coiled

MULTI USE See Description

114 Fits All Versions.

$1.30
19-115
019-1181665
$5.50
20-114
020-1181766☀
20-114 Spring, Eccentric Spring

114 Fits All Versions.
114H Fits All Versions.

$3.65
21-114
021-1181845☀
21-114 Lever, Eccentric Lever

114 Fits All Versions.
114H Fits All Versions.

$5.50
23-60
023-1181935☀
23-60 Screw, Large

MULTI USE See Description

$4.55
23-116
023-1181946☀
$6.45
24-115
024-1182001
24-115 Handle, Chromed Blade, Large Plastic Knob

FITS: Type [C] Bridge/Sleeve

REPLACED BY PART NUMBER 24N-57

Direct product replacement: 24N-57 Handle, Newer Ergo Plastic Knob $46.40

$0.00
26-114
026-1182118
26-114 Bearing, Friction Bearing, Handle Side

MULTI USE See Description

114 Fits All Versions.

$0.00
26N-116
026N-1182119▲
26N-116 Bearing with Cap, Ball Bearing, Handle Side


REPLACES ORIGINAL NUMBER 26-116 ON SOME REELS

$23.30
29M-115
029M-1182584
29M-115 Spool, Chrome on Bronze

REPLACED BY PART NUMBER 29L-115

Direct product replacement: 29L-115 Spool, Aluminum (Black) $88.80

$0.00
30-115
030-1182623▲
$29.05
32-21
032-1182713☀
32-21 Screw

MULTI USE See Description

Used on multiple models in different quantities.

$1.30
33-114
033-1182755▲
33-114 Rod Clamp, Metal

MULTI USE See Description

Does not fit 30T reel.

114 Fits Frame Posts Version.
114H Fits Frame Posts Version.

$7.90
33R-114
033R-1182779▲
33R-114 Ringed Rod Clamp, Metal (Made in China, Brushed Stainless)

Does not fit 30T reel.

See Description

Used on multiple models in different quantities.
114 Fits Frame Posts Version.
114H Fits Frame Posts Version.

$14.55
33-340
033-1182760
33-340 Clamp, Rod, Graphite

114 Fits All Versions.
114H Fits All Versions.
Direct product replacement: 33-114H2 Clamp, Rod Clamp, Graphite with ring $13.85

$0.00
33-114H2
033-1197532☘
33-114H2 Clamp, Rod Clamp, Graphite with ring

Same As: 33N-340 (New 33-340 with Overboard Ring)

114 Fits All Versions.
114H Fits All Versions.

$13.85
33C-SQL50LW
033C-1308829▭
33C-SQL50LW Clamp, Rod, KIT: Ringed Graphite Clamp with Studs, Nuts and Wrench

114 Fits Frame Posts Version.
114H Fits Frame Posts Version.

$21.80
34-45
034-1182788▲
34-45 Screw, Rod Clamp Screw (Shorter for Thick Clamps) ONLY (uses 2)

This is just the stud

114 Fits Frame Posts Version.
114H Fits Frame Posts Version.

$1.50
34C-45
034C-1182862▲
34C-45 Screw With Nuts, for Thick Style Rod Clamp (uses 2)

114 Fits Frame Posts Version.
114H Fits Frame Posts Version.

$5.85
34-200
034-1182810▲
34-200 Screw, Clamp Screw (Longer for Thin Clamp) ONLY (uses 2)

This can be used as a sub for the 34-49 or 34-45 if wanting a LONGER stud screw

$2.55
35-115
035-1182916☀
$1.80
37-115-BS
037-1183069▲
37-115 Post, Frame Post (BRUSHED STEEL) (uses 5)

114H Fits Half Frame Version.

$5.50
37-115-C
037-115C
37-115 Post, Frame Post (ORIG. CHROME) (uses 5)

114H Fits Half Frame Version.

$0.00
39-12
039-1183184♦
39-12 Screw

Used on multiple models in different quantities.

$1.30
39-13
039-1183185♦
$1.30
40-114H
040-1183273☀
$21.85
54-114
054-1183857☀
54-114 Lug, Harness Lug, Thin (uses 2)

MULTI USE See Description

Used on multiple models in different quantities.

$2.60
56P-117
056P-1183913☀
56P-117 Pad, Rod Brace Rubber Pad

Used on multiple models in different quantities.

$1.50
86-115L
086-1184255★
$1.50
98-114AT-LH
CAT-098-98-114-SS-LH
$36.00
99-115
099-1184401☀
99-115 Hook Screw, upper part of harness, LH threading, short (1.37 in)

Click for installation and hook identification notes.

$2.85
110-60
110-1184437♦
110-60 Screw, Handle Lock Screw

REPLACES ORIGINAL PART NUMBER 23A-60 ON SOME REELS

$1.30
149-45
149-1184702♦
149-45 Nut, Clamp, Long, for Thick Clamps (uses 2)

Used with the graphite clamps 33-340, 33N-113, aluminum 33-TRQ, 33-TRQS and iron alloy clamp 33i-113 and 33-16VS

$1.60
168-115
168-1184804☘
168-115 Wrench

FITS 23-50S, 23-114, 23M-114, 23-116, 23-220, 23-FTH20LW, 23-16S, 23-60 knurled nuts

$1.30
168-TANI
CUU-168-TANi▭
168-TANI Heavy Duty Penn Handle Nut Wrench by Alan Tani

Aftermarket Part - Not Manf. by Penn (see details for list of reels)
Fits 23-50S, 23-60, 23-114, 23-116, 23-220, 23-FTH20LW, 23-16S knurled nuts

$20.00
168-9
168-1184800
168-9 Wrench

Fits 23-60 knurled nut (see details for list of reels)
partimage

REPLACED BY PART NUMBER 168-60 or 168-TANI

Direct product replacement: 168-60 Wrench $1.30

$0.00
168-60
168-1184802☘
168-60 Wrench

Fits 23-60, 23-16S knurled nuts (See details for list of reels)

$1.30
